WARNING:
Always lift up the squeegee at the end of
cleaning in order to prevent the deforma-
tion of the rubber blades.
- Disconnect the electric power cable from
the socket (for E version only).
10.1 DRAINING THE RE-
COVERY WATER
(Fig. 13)
At the end of the washing cycle or when the
recovery water tank (1) is full, it is necessary
to empty the tank by proceeding as follows:
N.B.:
To dispose of the recovery water, comply
with the standards in force in the country in
which the machine is used.
- Position the machine near to a drain out-
let.
- Disconnect the hose (2) from the support
(3).
- Remove the cap (4) from the hose (2)
and drain all the water contained in the
tank.
It is possible to remove the tank (1) to drain
the water contained in it, proceeding as fol-
lows:
- Disconnect the hose (2) from the support
(3).
- Remove the hose (5) from the tank (1).
Place the cap (6) on the tank then lift the
tank and move it to the draining area.
N.B.:
The tank (1) is easy for one operator to lift as
it weighs less than 25 kg.
1
6
5
1
EN-17
EN
3
2
2
4
1
Fig. 13
