2 TRANSPORTATION

2.1 General warnings

The product and its packaging weigh about 3.4 kg (7.5 pounds) and can therefore be moved by hand.
WARNING
Personnel handling the load must work with safety gloves and footwear.

2.2 Package contents

Before using the device, check that it has not suffered damage during transportation or storage. Also
check that all the components supplied with it are contained in the package (refer to list). If you
identify any damage, notify the carrier and your supplier.
Contents of the control system packaging:
B501
A
B502
WARNING
Dispose of packaging in accordance with the law.
REF
A 1 lever control
B 4 screws M5x30
C 4 nuts M5
D 4 washers
E 3 snap rings
F 1 kit K59 for cable installation
G 1 screw M5x12
H 1 plate
I 1 pin
A
SINGLE LEVER CONTROL B501 AND B502
Installation and maintenance manual
B501
B
D
C
F
B502
1 lever control
4 screws M5x30
4 nuts M5
4 washers
6 snap rings
2 kits K59 for cable installation
2 screws M5x12
2 plates
2 pins
G
E
I
