2 TRANSPORT

2.1 General warnings

The product weight with its packaging is 3kg (7 pounds) and so it can be handled manually.
WARNING
The staff in charge of handling must operate with protective gloves and safety shoes.

2.2 Packaging contents

Before using the equipment check that the product has not been damaged during transport.
Also make sure that all the standard components are in the packaging (see list). In case of damage,
notify the claim to the forwarder and inform the supplier.
UC 68-OBS
l
D
CONTENTS OF THE STANDARD PACKAGING:
A ) No.1 cylinder body:
B ) No.1 extention;
C ) pin;
D ) No.1 plastic hose for the hydraulic circuit bleeding;
CAUTION
The packaging must be disposed of according to the existing laws.
A
l
l
l
C
B
HYDRAULIC CYLINDER FOR SIDE MOUNT APPLICATIONS
Installation and Maintenance Manual
UC 132-OBS
l
l
l
D
B
UC 133-IOB
l
l
l l
D
C
B
-
A
l
C
A
