Instructions for assembly and use

1.2.0 USE AS INTENDED

The purpose of the control unit is solely for controlling sauna heaters.
This device is a sauna control device which possesses the following functions:
•
control of sauna heaters up to 9KW
•
operation/ dimming of a cabin light
•
(optional: control of a evaporator)
•
(optional: control of a ventilator)
For basic operation (= Finnish operation) a sauna cabin with a sauna heater is required in addition
to the basic package
Figure 18: operating unit
The instructions in the installation guide must absolutely be
complied with when wiring the components.

1.3.0 MODE OF OPERATION

The control unit is ready for operation as soon as all assembly work is complete. When it is
connected to the mains, the self test starts, during which all LEDs illuminate. The control unit then
switches into stand-by mode and the
the button.
The control unit starts, the internal illumination is activated.
The Wave.com4 sauna control unit regulates the temperature inside the cabin. When the set
temperature is reached, the heating rods in the sauna heater are switched off. Then heating rods
are continuously switched on to maintain the set temperature.
WE DO IT FIRST.
(wave.com4 power unit with operating unit, sensor and cable).
Figure 19: Wave.com4 power unit
LED lights up. The control unit is activated by pressing
10 /228
