7 - CONTROL

User parameters

The list includes the parameters accessibile to the user, according to the unit configuration some parameters are visible and some not.
Num. Description Extended description
Enabling compensation on external temperature
4 CompExt
0=No
1=Cool
2=Heat
3=Always
10 MantCoolEn Enable Summer maintenance
11 MantHeatEn Enable Winter maintenance
51 SetCool
System water Summer Set Point
52 SetHeat
System water Winter Set Point
53 SecondSetC System water Secondary Summer SetPoint
54 SecondSetH System water secondary Winter SetPoint
55 SetCoolC2 system water Summer Set Point secondary circuit 2 (cs2)
56 SetHeatC2 system water Winter Set Point cs2
61 SecondSetC2 system water Secondary Summer SetPoint cs2 (economical)
62 SecondSetH2 system water secondary Winter SetPoint cs2 (economical)
112 CExtMaxC
External Summer temperature at which maximum correction of system water setpoint takes place
113 CExtMinC
External summer temperature at which minimum correction of system water setpoint takes place
114 CExtMaxH
External Winter temperature at which maximum correction of system water setpoint takes place
115 CExtMinH
External Winter temperature at which minimum correction of setpoint takes place
116 MaxCExtC
Maximum correction value of system water setpoint in Summer
117 MaxCExtH
Maximum correction value of system water setpoint in Winter
120 CextMaxC2 External Summer temperature at which maximum correction of cs2 system water setpoint takes place
121 CextMinC2 External Summer temperature at which minimum correction of cs2 system water setpoint takes place
122 CextMaxH2 External Winter temperature at which maximum correction of cs2 system water setpoint takes place
123 CextMinH2 External Winter temperature at which minimum correction of cs2 system water setpoint takes place
124 MaxCExtC2 Maximum correction value of cs2 system water setpoint in Summer
125 MaxCExtH2 Maximum correction value of cs2 system water setpoint in Winter
247 SetMantCool Summer Maintenance Set Point
248 SetMantHeat Winter Maintenance Set Point
429 SetAccumulo Set Point sanitary hot water of the internal accumulation.
431 BandaMant Maximum variation allowed inside accumulation
435 EnAntilegio Enable anti-legionella
0=Not managed,
439 EnRicircolo
1=Enabled,
2=Only enabled in Heat,
3=Only enabled in Cool
628 IstTAmb Ambient temperature hysteresis
893 CompExtC2 Enabling compensation on external temperature
0=No
1=Cool
2=Heat
3=Always
47
