10 Description of the options in the engineer's menu

Depending on which modules or power elements are connected, the respective menu points are displayed
or hidden.
Depending on which settings are undertaken in the engineer's menu, individual menu points are
displayed or hidden.
Factory settings are written in bold
10.1

wave.com4 sauna control option

• Evaporator
• Ventilator
module.
• Bench sensor
• Res5 function
Also observe the information in the operating and installation instructions of the wave.com4 sauna
control
10.2 wave.com4 option – sauna control- remote contact
Here you can specify whether the Wave.com4 sauna control should remain switched on after
termination of the remote contact voltage:
Switch on (select = 'On')
Switch off (select 'Off')

10.3 Infrared option

Ventilator
Switching output 1
Switching output 2
Remote start

10.4 wave.com4 Infra remote start option

Here you can preset the control whether the Wave.com4 Infra (infrared control) should react to
remote start or not. The Wave.com4 Infra infrared control is started remotely by means of a switch.
Further information relating to the Wave.com4 Infra remote start can be found in the operating instructions
of the Wave.com4 Infra.
WORLD OF WELLNESS
Instructions for installation and use – only for experts
Off/on When the extension circuit board is connected (WC4-H-PCB)
deactivates the evaporator output and hides the 'Humidity' menu point
in the home screen.
On/off Activates the ventilator output on the wave.com4 sauna control basic
The ventilator output of the wave.com4 Infra is then automatically
deactivated.
Off/on
Nw (Evaporator water-failure function)/Rs (remote start). Activates the
remote start on the wave.com4 sauna control basic module. The water-
failure detection is then no longer available. The remote start input of
the wave.com4 Infra is then automatically deactivated.
Off/on
Activates the ventilator output on the wave.com4 Infra. The ventilator
output of the wave.com4 sauna control basic module is then
automatically deactivated.
Off/on Activates the potential -free OPT1 output. This switches off
automatically upon changeover into stand-by mode.
Off/on
Activates the potential-free OPT2 output. This switches off
automatically upon changeover into stand-by mode.
Off/on; Activates the remote start input on the wave.com4 Infra. The remote
start input of the wave.com4 sauna control basic module is then
automatically deactivated. Please observe the instructions in the
operating and installation instructions of the wave.com4 Infra.
P. 12/22
