3.8

PRINTING RECORDED VALUES (PRINT MEM)

PRINTING RECORDED V PRINTING RECORDED VALUES (PRINT MEM)
Recorded values can be printed with the switch in any position except SET-UP or OFF.
PRINT MEM
2
nd
+ PRINT
01 01 : 1 memory location used memory location used
st st st
06 05 : last memory location used
PRINT
Printing of all measurements
between he 1st and last
memory location selected memory location selected
4.1 VOL VOLT VOLT TAGE MEASUREMENT T AGE MEASUREMENT
4.1.1 DESCRIPTION OF THE FUNCTION
Voltage measurement is accessible with the switch in any position except SET-UP or OFF.
4.1.2 PREPARA PREP PREPARA ARA ARATION OF THE MEASUREMENT (CONNECTION) TION OF THE MEASUREMENT (CONNECTION)
=> Switch the instrument on
=> Connect the instrument to the installation using
the measuring cable terminated by a mains plug,
or
=> Use the separate cables to make the connection.
4.1.3

MEASUREMENT PROCEDURE

Once connected, the instrument indicates any voltage(s) present on its terminals.
Do not use the instrument on an electrical installation exceeding 550V with respect to earth
www.electronicaembajadores.com

4. MEASUREMENTS

54
to select the values to be printed
