Mounting the camera
Connecting the camera
I
NOTE
• Lay the camera cable so that should you need to remove the camera,
you can access the plug connection between the camera and the
extension cable easily. This considerably eases dismantling work.
• To minimise corrosion in the plug, apply a small amount of grease –
such as pin grease – inside the plug.
• Additional extension cables are available on request (see chapter
"Accessories" on page 13).
➤ Guide the camera cable into the vehicle interior.
➤ Insert the plug of the camera cable into the socket of the extension cable.
➤ Screw on the plug connections of the connecting cables to protect against water
penetration (fig. h, page 7).
Aligning the camera
I
NOTE
If necessary before aligning the camera connect the camera to a monitor
and to a power supply (see connecting diagram, fig. i, page 7
➤ Use the monitor image to align the camera:
The monitor image should show the bottom edge of the rear or the bumper of
your vehicle (A). The middle of the bumper should be in the middle of the
screen. (fig. j, page 7).
➤ Check the function of the camera after you have connected it to a monitor.
Fastening the camera
➤ Thighten the two screws in the slots of the camera bracket.
➤ Mount the side covers with the two screws M3 x 8 mm in the middle drill holes
(fig. k, page 8).
