CAM50
• When working on the following lines, only use insulated cable lugs, plugs and
tab sleeves:
– 30 (direct supply from positive battery terminal)
– 15 (connected positive terminal, behind the battery)
– 31 (return line from the battery, earth)
– 58 (reversing light)
Do not use porcelain wire connectors.
• Use a crimping tool (fig. 1 10, page 3) to connect the cables.
• When connecting to supply line 31 (earth), screw the cable
– To the vehicle's earth bolt with a cable lug and a gear disc or
– To the sheet metal body work with a cable lug and a self-tapping screw.
Ensure that there is a good earth connection.
When the negative terminal of the battery is disconnected, all data stored in the
volatile memories will be lost.
• The following data must be set again, depending on the vehicle equipment
options:
– Radio code
– Vehicle clock
– Timer
– On-board computer
– Seat position
You can find instructions for making these settings in the appropriate operating
instructions.
Observe the following installation instructions:
• Secure the parts of the camera installed in the vehicle in such a way that they
cannot become loose under any circumstances (sudden braking, accidents) and
cause injuries to the occupants of the vehicle.
• Secure any parts of the system covered by the bodywork in such a manner that
they cannot be come loose or damage other parts and cables and impair vehicle
functions (steering, pedals, etc.).
• To prevent damage, when drilling ensure that there is sufficient room for the drill
head to come out on the other side (fig. 2, page 4).
• Deburr all drill holes and treat them with a rust-protection agent.
• Always follow the safety instructions of the vehicle manufacturer.
Some work (e.g. on retention systems such as the AIRBAG etc.) may only be
performed by qualified specialists.
EN
Safety and installation instructions
11
