OPERATION
A few seconds after connecting to the mains, the spotlight is ready for operation and the previously selected operating mode is activated.
CONFIGURE DMX START ADDRESS
Press the MODE button repeatedly until "Addr" appears in the display. Now press ENTER and configure the DMX start address using the UP
and DOWN buttons as required (A001 - A512). Confirm your entry with ENTER. Synchronous control of several lamps of the same model
with a DMX controller (e.g. DMX console) can be achieved by configuring the lights with the same DMX starting address and the same DMX
mode setting and with the help of DMX cables.
-> ENTER ->
DMX MODE SETTING
Press the MODE button repeatedly until "MOdE" appears in the display. Now press ENTER twice and select the desired DMX mode by using
the UP and DOWN buttons as required (02Ch, 04Ch, 11Ch, 16Ch, 19Ch). Confirm your entry with ENTER. Tables with the channel assignment
of the different DMX modes can be found in these instructions under DMX CONTROL. If there is no DMX signal to the device, the characters
in the display will flash. If there is a DMX signal, the display will stop flashing.
-> ENTER ->
CONFIGURING STANDALONE MODE
Press the MODE button repeatedly until "MOdE" appears in the display. Now press ENTER twice and select the desired standalone mode by
using the UP and DOWN buttons as required (Soun, SLAV, AUto). Confirm your selection with ENTER.
-> ENTER ->
SLAVE MODE
After you have selected Slave mode as described in CONFIGURING STANDALONE MODE, confirm the selection by pressing ENTER. Connect
the slave and the master units (same model) with a DMX cable and enable one of the standalone modes on the master unit: automatic-con-
trol, or sound-control. Now the slave unit will follow the master unit.
AUTOMATIC CONTROL MODE (AUTO)
Select one of the 13 different auto programmes (Au00 - Au12) and configure the programme running speed (SP00 - SP99). After you have
activated the automatic-control mode as described in CONFIGURING STAND-ALONE MODE, press ENTER. The characters in the display will
begin to flash and you can select the desired programme by using the UP and DOWN buttons. Confirm selection with ENTER, select menu
item SPxx using the UP and DOWN buttons, and confirm selection with ENTER. You can now adjust the programme run speed as required
from 00 to 99 with the UP and DOWN buttons. (00= minimum, 99 = maximum speed). Confirm with ENTER. If no further commands are
entered, the display automatically returns to the main menu, and the programme number is displayed.
-> ENTER ->
SOUND-CONTROL MODE
Activate the sound-control mode as described in CONFIGURE STANDALONE MODE in order to control the spotlights via the built-in
microphone. (bass impulses). Now set the microphone sensitivity as required using the UP and DOWN buttons (Se00 = minimum - Se99 =
maximum sensitivity). If no further commands are entered, the display automatically returns to the main menu after about 10 seconds, and
"Soun" is displayed.
-> ENTER ->
6
UP/DOWN
-
-> ENTER ->
UP/DOWN
UP/DOWN
/
-> ENTER ->
UP/DOWN
-> ENTER ->
UP/DOWN
-
-> ENTER
<- MODE
/
/
-> ENTER
/
<- MODE
-> ENTER
/
<- MODE
UP/DOWN
-
UP/DOWN
-
-> ENTER
<- MODE
/
-> ENTER
<- MODE
-> ENTER
<- MODE
