Construction and design

The HF03/HF02 valve system is composed of the following
components:
W
Right end plate for connecting the pneumatics
W
From 1 to 16 subplates for valves, supply plates or dummy
plates
W
Left end plate for the pneumatic connection with an
integrated multiple plug connector I.
3.2

Valves

Directional-control valves complete with pilot control valve:
W
3/2 directional-control units (2 independent valves per unit),
W
5/2 and 5/3 directional-control valves.
1 or 2 manual overrides depending on the valve model
(with 1 or 2 solenoids), can be operated independently of each other
in 2×3/2 valve units:
W
Yellow knob: turn and detent
W
Red knob: turn
Yellow LED (depending on the solenoid coil); marking:
W
14 in valves with one solenoid
W
14 and 12 in valves/valve units with two solenoids
3.3

Components for pneumatics

W
Subplate (parts kit) to expand the valve block at a later date,
however, the maximum number of valve positions is limited
to 16.
W
Valves
W
Supply plate
W
Dummy plate
W
Separator
W
Mounting kit for DIN rail, DIN EN 60715, 35×15
49
System architecture
