Indexa DVT30 Mode D'emploi page 50

Note:
#
Motion detection is only possible when detection areas within the camera image have been selected.
#
Camera 1 in the outdoor station cannot be set as motion detection function is not available.
[97] - FORMAT STORAGE
Formats the inserted micro-SD card when symbol is pressed.
Note: During formatting all data on the card will be deleted. If required save the data elsewhere before formatting.
[98] - SETUP MASKING AREA for motion detection
In order to avoid unwanted motion activated recordings due to changes in the background, for example movement of plants or trees in the wind, it is
possible to mask specific areas in each camera picture. The areas which are not sensitive to motion are marked in blue.
[87] - EVENT LIST
!
‡ ˆ
Press and to scroll the list of files.
The files are sorted by date and hour and then chronologically.
Displayed is:
#
The start and end time of the recording
#
The type of recording (M= motion detection / S= schedule / X= by pressing of the record button or of the door bell button)
#
Motion detection (cameras 2-4) or press of the door bell button (camera 1) during a recording will be marked with the relevant camera number [66].
View or delete a file on the monitor
!
Select a file by tapping it, The recording is displayed as full image if only the outdoor station camera is activated and as quad if any additional camera is
paired and activated.
!
When viewing a quad image repeatedly press the image symbol to sequence through the full images and quad (if a camera was deactivated a blank
image will be shown).
!
To fast forward press the forward button
!
Press the Pause button to see a still image and the button to continue playing.
!
To return from the playback to the event list press the File button.
!
To delete a file, a complete hour or a complete day, hold the file pressed until the bin symbol appears. Confirm deletion by pressing the bin symbol, or quit
by pressing the quit symbol.
Note:
If the volume has been muted in the control bar, the recorded audio cannot be heard. Exit the main menu, open the control bar and increase the volume
before returning to the recorded file, the sound is now audible.
[86] - SYSTEM SETUP
[101] - DATE AND TIME
year / month / date / morning or afternoon / minute
[102] - TV (video) OUTPUT
For use in Europe this should be left as PAL
Default: PAL
[103] - POWER SAVING
This mode enables the automatic deactivation of the screen after an idle time. Select betweenscreen off after 5 minutes idle, screen off after 10
minutes idle or screen always on.
Default: Screen always on.
[104] - Display image in idle mode (MULTI CHANNELS IDLE DISPLAY)
After a period of two minutes without any buttons being pressed by the user, the displayed image changes to the idle image which can be selected
between: DISPLAY QUAD DURING IDLE TIME / DISPLAY DOORPHONE (outdoor station) DURING IDLE TIME / AT 10 SEC INTERVALS (the camera in the
outdoor station and any other activated camera will be displayed in sequence / AT 10 SEC INTERVALS W/O DOORPHONE (any additional camera will
be displayed in sequence, if only one additional camera is activated this will be displayed continuously)
Note: If only the camera 1 in the outdoor station is activated then this image will be displayed continuously.
Default: DISPLAY DOORPHONE DURING IDLE TIME
50 - GB
··
and to rewind the rewind button
·
II
¶¶
.
