4. Features and Equipment (s. fig. A)
Indoor station DVT30M with control bar
1 microphone
2 monitoring
3 indoor station
4 current camera
5 audio indicator
6 battery indicator for indoor
station
7 date and time
8 screen indicator
full screen
1
full screen zoom (2x)
2x
quad
sequence
9 record indicator
10 connection indicator
11 connection LED
12 power-LED
13 battery LED for outdoor station
14 ontrol bar c
/ 15open/close
control bar
Outdoor station DVT30K
41 outdoor station
42 microphone
43 daylight sensor
44 lens
45 infrared-LEDs
46 speaker
47 doorbell button with name
plate
48 antenna connection
49 cover
50 seal
51 cover
52 screw
53 screw
54 pairing button
55 Batteriefach
56 connections (see also Fig. B)
Accessories
33 extension cable
34 CD with viewer software
35 antenna
36 screwdriver
37 connection cable
38 cable 1 m
16 image button
17 audio button
(possible only with
outdoor station)
18 door release button
19 gate release button
20 volume button
21 record button
22 menu button
23 fixing point for spacer
24 on/Off button
25 speaker
26 wall mount hole
27 antenna
28 audio/video output
29 reset button
30 slot for micro-SD card
31 stand
32 mains adapter connection
57 gate release connection
58 gate release connection
59 mains adapter
connection
—
60 mains adapter
connection +
61 door release connection
62 door release connection
63 sun shield
64 hole for antenna cable
65 mounting hole
66 cable hole when antenna
cable not used
67 hole for security screw
68 antenna hole (with seal)
106 Bridge cable
39 cable 2 m
40 A/V cinch cable
69 mains adapter 12 V DC
70 mains adapter 5 V DC
71 security screws
72 antenna cable
73 spare name plate
74 spare cover for bell push
75 screw
76 plug
77 spacer
Example connection for door release
Fig. B: Connection of door release with separate power supply
Fig. C: Connection of door release with power supply from outdoor station
mains adapter
Menu symbols (see Fig. E-H)
Main Menu (see Fig E)
81 Camera settings
82 Recording settings
83 Digital zoom
84 Alarm on/off
85 Return button
86 System settings
87 Event list
88 Start sequence manually
89 Ring recording on/off
Camera settings (see Fig. F)
90 Camera 1 for outdoor station
91 Pairing
92 Cameras 2-4
93 Brightness
94 Activate /deactivate camera
Record settings 95 24 hour recording schedule
96 Sensitivity of motion detection
97 Format micro-SD card (delete recorded data)
98 Area for motion detection
99 Type of automatic recording
100 Time period (one hour)
System settings
101 Date and time
102 Video output
103 Energy saving
104 Screen in idle mode
105 Menu language and factory default

5. Technical data

Outdoor station DVT30K
Operating Voltage 15 V
or 6 x AA 1.5 V alkaline battery (LR6)
Current consumption max. 300 mA
Switching power of door release relay max 1,5 A at up to 15 V AC/DC
Relay switching time door release (62/62): 5 sec.
gate release (57/58): 1 sec.
Camera image sensor 1/4" CMOS colour
78A spare seal for cover (50)
78B spare seal for antenna hole (67)
79 bracket
80 distance piece
"
DC (mains adapter)
GB - 43
