X-ray cassette tray (Optional)

The X-ray cassette tray allows thoracic X-ray photography with the backrest
at any angle and without the patient moving from the bed.
WARNING
Position the mattress platform at an ergonomic height to allow easy loading and
removal of X-ray cassettes.
Return the X-ray cassette tray to its closed position below the backrest before raising
or lowering the backrest.
Do not sit or place heavy objects on the X-ray cassette tray.
Ensure the X-ray cassette tray is held securely in place by the catch at all times.

Operation

Apply the brakes. Remove the head board from the bed.
Pull the knob (1) to release the catch and slide the tray out (2) as far as will
go.
Release the knob to hold the tray in the fully open position (3). Position the
X-ray cassette (4) on the tray with its bottom edge against the lip at the foot
end of the tray.
2
X-ray cassette tray operation
1
