Route Electrical Wiring

WARNING
Electrical Shock Hazard
Disconnect electrical power at the fuse box or circuit
breaker box before installing dishwasher.
Failure to do so can result in death or electrical shock.
Follow all national and local codes and ordinances for completing
electrical supply to cabinet.
Option 1: Right-hand side utility route
Route wire through 1½" (3.81 cm) hole located 8" (20.32 cm) above
the floor.
After routing the electrical wire through the right-hand hole, attach
the wire to back left-hand side of cabinet wall 8" (20.32 cm)
above the floor. Then continue routing the wire along the left-hand
side of cabinet opening to the front of the opening.
Option 2: Left-hand side utility route
Route wire through 1½" (3.81 cm) hole located 8" (20.32 cm) above
the floor.
After routing the electrical wire through the left-hand hole,
continue routing the wire along the left-hand side of cabinet to the
front of the opening.

Route Water Supply Line and Drain Hose

1. Connect water supply line to water valve on dishwasher.
2. Route water supply line and drain hoses based on your
cabinet requirements.
Option 1: Right-hand side utility access
For right-hand routing, drain hoses are shipped in the
correct position. Place the water supply line in the clip as
shown.
