OVERLAY PANEL INSTALLATION INSTRUCTIONS
If you plan to install custom wood panels, you will need to create
the panels yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for panel specifications.
IMPORTANT:
The thickness of the overlay panel must be ¹⁄₂" (12.7 mm) to
³⁄₄" (19.05 mm).
Overlay Panel Dimensions
Upper drawer panel
3
/
"
4
(1.9 cm)
Hardware Installation
Center the hardware (left to right) onto the overlay panel. When installing the hardware, be sure that the mounting screws are flush with
the back of the overlay panel(s).
1. Lay the custom panels (top and bottom) face down on a
clean, soft work surface.
2. Using a pencil, mark the centerpoints for the two panel
fastener pilot holes and six pilot holes needed for the upper
panel.
1
11
/
"
4
(28.5 cm)
1
2
/
"
2
1
8
/
"
8
(6.3 cm)
(20.7 cm)
A. Center line
B. Panel fastener pilot holes (2)
C. Pilot holes (6)
16
Custom Overlay Drawer Panels
7
23
/
"
16
(59.5 cm)
Preparing Custom Panels
A
1
11
/
"
4
(28.5 cm)
1
1
/
"
2
1
8
/
"
(3.8 cm)
8
(20.7 cm)
(20.2 cm)
B
C
Do not exceed the height dimension for the overlay panel(s).
Panel(s) that exceed the height dimension may damage the
drawer dishwasher, cabinets or countertop.
The width of the overlay panel(s) may vary according to the
width of the cabinet opening.
Lower drawer panel
1
16
/
"
4
(41.3 cm)
3
/
"
4
(1.9 cm)
3. Mark the centerpoints for the two panel fastener pilot holes
and four pilot holes needed for the lower panel.
1
2
/
"
2
(6.3 cm)
8"
1
14
/
"
8
(36.6 cm)
4. Using a ¹⁄₈" drill, drill each hole ³⁄₈" (1cm) deep.
(1 cm)
IMPORTANT: To avoid drilling through to the front of the
overlay panel, do not drill deeper than 3/8" (1 cm).
23
7
/
"
16
(59.5 cm)
A
1
1
11
/
"
11
/
"
4
4
(28.5 cm)
(28.5 cm)
1
1
8
/
"
8
/
"
8
8
(20.7 cm)
(20.7 cm)
B
C
A. Center line
B. Panel fastener pilot holes (2)
C. Pilot holes (4)
3
12
/
"
4
(61 cm)
1
1
/
"
2
(3.8 cm)
1
10
/
"
2
(26.7 cm)
