Product Dimensions
24"
(61 cm)
¹⁄₄
19
"
(48.9 cm)
A hot water line with 20-120 psi (138-862 kPa) water pressure.
120°F (49°C) water temperature at dishwasher.
Cutout dimensions
³⁄₈
23
"
(59.5 cm)
33³⁄₄"
(85.7 cm)
Preferred utililty area
¹⁄₂
1
"
(3.75 cm)
NOTE: All holes should be drilled at 1½" (3.8 cm) diameter.
Water Supply Requirements
Installation Clearances
(59.7 cm)
1/2"
(1.3 cm)
25"
(63.5 cm)
A. Choose left-hand or right-hand drain and water connection route.
B. Choose left-hand or right-hand electric connection route.
Flexible braided fill line (½" minimum plastic tubing is not
recommended).
23¹⁄₂"
24"
33³⁄₄"
(61 cm)
(85.7 cm)
A
B
8"
(20.3 cm)
5
