Commissioning
7

Linear V/f-characteristic control

The following instructions apply to controllers equipped with a Standard-I/O module and an
accordingly selected three-phase AC motor
Switch-on sequence
1. Attach the keypad
2. Ensure that controller inhibit is
active after mains connection.
3. Switch on the mains
4. The keypad is in "Disp" mode after
approx. 2 s and indicates the output
frequency (C0050)
f
5.
Change to the
configure the basic settings for your
drive
6. Adapt the voltage range/current
range to the analog setpoint (C0034)
Lenze setting: -0-, (0 ... 5 V/0 ... 10
V/0 ... 20 mA)
7. Adapt the terminal configuration to
the wiring (C0007)
Lenze setting: -0-, i. e.
E1: JOG1/3 JOG frequency selection
E2: JOG2/3
E3: DCB DC brake
E4: CW/CCW operation
32
Œ
‚ m n o
Hi
Lo
z
mode to
w x
y
z
w x
y
z
w x
y
EDK82EV222 DE/EN/FR 6.0
d c b e a
j g f k i h PS
p
q r
Hz
d c b e
Œ
j g f k i h PS
‚ m n o
p
q r
Hi
Lo
d c b e
Πj g f k i h PS
‚ m n o
p
q r
Hi
Lo
d c b e
Πj g f k i h PS
‚ m n o
p
q r
Hi
Lo
Note
Terminal X3/28 = LOW
U U U U S S S S E E E E r r r r
The menu is active
Blinking on the display:
a
0 0 0 0 0 0 0 0 5 5 5 5 0 0 0 0
Hz
Set the DIP switch on the
a
standard-I/O to the same
range (see Mounting
Hz
Instructions for the
standard-I/O)
a
Hz
L
