Function module (optional)

6

Mounting

Danger!
The pins of the FIF interface carry dangerous voltage!
Install the function module only when the controller is disconnected from the mains.
l
After disconnection from the mains wait for at least 3 minutes before you start
l
working on the module.
1 2
OFF
3 min
4
20
3
5
PES
PES
6mm
EDK82EV222 DE/EN/FR 6.0
1. Disconnect the controller
from the mains and wait for
at least 3 minutes!
2. Remove and store dummy
cap
3. Remove and store FIF cover
4. Connect function module
FIF interface.
5. For wiring, see Mounting
Instructions for the function
module.
0,5...0,6
Nm
4.4...5.3
lbin
2
1 mm
AWG 18
8200vec007
0
.
1
2
