Technical data

Weight:
Dimensions without connections:
Connection:
Atomiser air
Control air
Material supply
Flushing connection
Nozzle sizes available:
Air Caps:
Pressure ranges:
Atomiser air pressure
Control air pressure
Material pressure
Max. operating temperature
of spray gun
Sound level
(measured at approx. 1 m
distance to spray gun)
Air consumption with air cap type 2.1:
Atomiser air
1,0 bar/ 15 psi
2,0 bar/ 29 psi
3,0 bar/ 44 psi
4,0 bar/ 58 psi
5,0 bar/ 73 psi
6,0 bar/ 87 psi
Subject to technical alterations.
294 g / 0,7 Ib
H = 29 mm
W = 22 mm
L = 128 mm
2 x M 7 - QS 6
2 x M 5 - QS 4
3 x G 1/8" - PK 4 hose 6x4 mm ø
1 x M 5
0.3 ▪ 0.5 ▪ 0.8 ▪ 1.0 ▪ 1.2 ▪ 1.5 mm ø
see table (page 32)
0 - 6 bar / 0 - 87 psi
min. 4 - max. 6 bar/ min. 58 - max. 87 psi
0 - max. 6 bar / 0 - max. 87 psi (GA 9010 Marking)
0,3 - 1,5 bar / 4 - 22 psi - (GA 9010 Marking-MB)
80 °C / 176° F (GA 9010 Marking)
50 °C / 122° F (GA 9010 Marking-MB)
1 bar / 15 psi = 64 dB (A)
6 bar / 87 psi = 83 dB (A)
Air consumption
35 l/min
54 l/min
74 l/min
100 l/min
125 l/min
148 l/min
