Operating the BRITT II/III/IV wooden side rail
The bed end may be equipped to lock the side rail at half height as
well as in the top position.
Normally the side rail can only be locked in top position.
Up: Pull up the top wooden side rail bar, until the locking pin locks
with an audible click.
Down: Lift the top wooden side rail bar and press the two locking
pins together. Lower the side rail.
Lift
Operating the steel side rail
Up: Lift the top steel bar of the side rail towards the end with the
locking mechanism.
Down: Press the release button and pull the top bar of the steel
side rail away from the locking mechanism.
There is risk of entrapment of fingers on assembly and operation of the side rails.
Please ensure that the side rail locking system has engaged properly by pulling / pushing the upper bar.
Adjusting the height of the lifting pole handle
Loosen the cord as shown in fig. A. The lifting handle can now be
adjusted to the desired height.
Press the cord together as shown in fig. B and check that the cord
is locked in the cord lock by pulling the handle.
Position the lifting pole in such a way that the
handle is above the bed. If the lifting pole is used
while the handle has been turned away from the
bed - the bed can tip when the handle is used.
Release
9
Locking pins
Lower
A B
