5.7

Wiring of the feedback system

5.7.1

Important notes

An incremental encoder can be connected to input X8 or input X9:
ƒ
– Incremental encoders with TTL level are connected to X8.
– Incremental encoders with HTL level are connected to X9.
The incremental encoder signal can be output for slave drives at the digital
ƒ
frequency output X10.
)
Note!
ƒ
ƒ
EDKVF9338 DE/EN/FR 4.0
We recommend to use Lenze system cables for wiring.
For self−made cables only use cables with shielded cores twisted in pairs.
l
Electrical installation
Wiring of the feedback system
Important notes
