one2clean
Item no.
106854 Installation kit 7 inhabitants
106855 Installation kit 10 inhabitants
106856 Installation kit 14 inhabitants
106857 Installation kit 18 inhabitants
The points described in these in-
structions must be observed in all
cases. Failure to do so shall invali-
date the warranty. For any addi-
tional items purchased through
GRAF, you will receive separate
installation instructions in the
transport packaging.
The components must be checked
for any damage before the system
is transferred to the pit.
You will receive separate instruc-
tions for operation and mainte-
nance of the system.
mail@graf.info
www.graf.info
one2clean Multi-Tank System
Installation instructions
Contents
1. SCOPE OF SUPPLY
2. PLEASE NOTE:
2.1 Safety
2.2 Ventilation
3. INSTALLATION AND OPERATING PRINCIPLE
4. FITTING THE INSTALLATION KIT
4.1 Drilling the tank shells
4.2 Assembly of first tank
4.3 Assembly of second tank
5. INSTALLING THE CONTROL ONE2CLEAN UNIT
INDOORS
6. INSTALLATION OF THE CONTROL UNIT IN THE
OUTDOOR CONTROL CABINET S
7. INSTALLATION OF THE CONTROL UNIT IN THE
OUTDOOR CABINET M
8. TECHNICAL DATA
15 / 80
16
17
17
17
18
19
19
19
21
24
25
26
27
