Clustering fixtures
The fixtures may only be connected directly to each other using Omega brackets in the following
mounting options (maximum two fixtures, two Omega brackets per fixture included in the packa-
ging content). Truss installation must be carried out with separate Omega brackets plus truss
clamps; it must not be carried out on Omega brackets as a connecting link between two fixtures.
Every fixture must be secured to the truss with a suitable safety rope!
INSTALLING THE FROST FILTER
A frost filter is included in the packaging content of the ROOTBAR6. To attach the frost filter to
the fixture, first loosen the three knurled screws on the front of the fixture, screw them out of the
threads as far as possible, and place the frost filter on the fixture (place the large openings of the
keyholes in the frost filter over the screw heads, see Fig. 1). Then slide the frost filter to the side
as far as it will go (Fig. 2). Now re-tighten the three knurled screws (Fig. 3).
1 2 3
