OPERATION
NOTES
• As soon as the fixture is switched on, the following are displayed in succession: "Welcome to
Cameo", the model name, and the software version. After this process, the fixture is ready for
operation, and the previously activated operating mode is launched.
• To return directly from the sub-menus to the main display, press and hold MENU for around two
seconds.
• The main display is activated automatically after approximately two minutes of no input. To
navigate one level up in the sub-menus, briefly press MENU.
• To directly access the previously edited menu item, briefly press MENU and ENTER at the same
time.
• Briefly pressing the ⏶ button when in the main display rotates the display by 180°.
• To quickly change a value, such as the DMX start address, press and hold ⏶ or ⏷.
MAIN SCREEN IN DMX OPERATING MODE
In DMX operating mode, the main screen shows the currently set DMX start address (see illustra-
tion). When the DMX Delay feature is activated, the delay group and delay time are also displayed.
Flashing characters in the display indicate that the fixture has no DMX signal.
MAIN DISPLAY STAND-ALONE OPERATING MODE
The display shows the currently activated stand-alone operating mode.
MAIN DISPLAY SLAVE MODE
The display shows Mode Slave. If the slave unit is assigned to a slave group, the slave group and
the delay time set in the master unit under the stand-alone operating modes Auto and Loop are
also displayed.
SETTING THE DMX START ADDRESS (DMX Address)
Starting from the main screen, press MENU to enter the main menu. Now use ⏶ or ⏷ to select
the menu item DMX Address and confirm with ENTER. Use ⏶ or ⏷ to configure the desired
