Cameo ROOT BAR 6 Manuel D'utilisation page 19

This takes you to the sub-menu for setting the sub-menu items (see table). The settings for each
loop are made independently and are retained even after restarting the device.
LOOP STAND-ALONE OPERATING MODE (Loop 1–Loop 4)
Sets the brightness
Sets the step time
Sets the fade time
Delay time for slave groups
Select color preset or blackout for step 1
Select color preset or blackout for step 2
Select color preset or blackout or skip step (––––) for step 3
Select color preset or blackout or skip step (––––) for step 4
SLAVE MODE
Standard slave operation: Starting from the main screen, press MENU to enter the main menu.
Use the ⏶ or ⏷ buttons to select the Slave menu item, confirm with ENTER, then select slave
group 0, and confirm again. Connect the slave and the master units (same model, same software
version) using a DMX cable and activate one of the stand-alone modes on the master unit. The
slave unit will now follow the master unit.
Extended slave mode: If you want to control the slave units in master/slave mode using one
of the stand-alone operating modes Auto, Pattern, or Loop, the control signal can be played
back with a time delay of up to 11 steps. The delay time is set in the menu of the master unit's
corresponding stand-alone operating mode; the delay factor in the slave menu of the correspon-
19
