WARNING:
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a second
is sufficient to inflict severe injury.
WARNING:
Always remove battery pack from the tool when you are
assembling parts, making adjustments, cleaning, or when
not in use. Removing battery pack will prevent accidental
starting that could cause serious personal injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes, resulting in possible
serious injury.
APPLICATIONS
You may use this tool for the purposes listed below:
„ Light wood assembly
„ Finish and trim work
„ Decorative moldings
„ Picture frame assemblies
„ Joint and dowel pinning
„ Window beading crafts
ATTACH BELT CLIP
See Figure 1, page 12.
The belt clip can be installed on the left or right side of the
nailer, depending on operator preference.
„ Align hole in belt hook with hole in tool's base.
„ Install screw to secure belt hook in place.
„ To uninstall, remove screw and then belt hook.
TO INSTALL/REMOVE BATTERY PACK
See Figure 2, page 12.
„ Insert the battery pack into the product as shown.
„ Make sure the latches on each side of the battery pack
snap into place and the battery pack is secured in the
product before beginning operation.
„ Depress the latches to remove the battery pack.
NOTE: Squeeze LED light grip switch to activate nailer.
For complete charging instructions, see the operator's manu-
als for your battery pack and charger.
OPERATION
NO-MAR PAD
See Figure 3, page 12.
The no-mar pad attached to the nose of the tool helps
prevent marring and denting when working with softer woods.
WARNING:
Remove the battery pack before removing or replacing
the no-mar pad. Failure to do so could result in serious
personal injury.
„ Remove the battery pack.
„ Remove the pad by pulling it up and away from the nose.
„ To replace the pad, fit it into place over the nose and
push down to reseat.
On-board storage for the pad is located on the magazine of
the tool. An extra no-mar pad is provided in the on-board
storage area.
LOADING THE TOOL WITH NAILS
See Figures 4 - 5, page 12.
„ Remove battery pack from the tool.
„ With the nose of the tool pointed away from you, feed
a strip of nails into the magazine. Be sure the nails are
pointed downward and at the angle shown.
WARNING:
Keep the tool pointed away from yourself and others
when loading nails. Failure to do so could result in pos-
sible serious personal injury.
„ Slide the pusher all the way to the rear of the magazine.
Release the pusher and allow it to push the nails up to
the driving mechanism. The pusher will stop when it rests
against the end of the nail strip.
NOTE: Do not allow the pusher to snap back into place.
WARNING:
Use only the nails recommended for use with this tool.
The use of any other nails can result in tool malfunction,
leading to serious injuries.
WARNING:
Never load nails with the workpiece contact or trigger
activated. Doing so could result in possible serious per-
sonal injury.
8 — English
