general Operating information
Double Wall Heating System
1.
Solar Collectors
2.
Mounting Brackets
3.
Straight Flexible Compression Fitting
4.
Elbow Compression Fitting
5.
plug Compression Fitting
6.
Solar Storage Tank
8
All manuals and user guides at all-guides.com
1
4
6
Additional
Temperature
Probe Port
(Optional)
Auxiliary
Electrial
Water Tank
Mixing Valve
3
5
7
To 120V Power Supply
Outlet to Backup
Heating System
10
7.
Solar Controller
8.
pumping Station - Solar Loop-A
9.
Expansion Tank - Solar Loop-A
10.
HXA pumping Station (ESDW2 only)
11.
HXA Expansion Tank (ESDW2 only)
5
1
3
2
8
To Pressure Relief
Collection Tank
80
80
9
To Pressure Relief
Collection Tank
80
80
11
Inlet from Main
Water Supply
www.renewables.dimplex.com
4
