ENGLISH

3. MAINTENANCE AND GUARANTEES.

3.1 HYDRAULIC INSTALLATION MAINTENANCE

Regular maintenance needs to be carried out on all components of the pool's hydraulic circuit in
order to ensure optimum operation of the installation and thereby prevent damage to the valve or
any other components.
The maintenance operations that may have a direct impact on the operation of the multiport valve
are listed below:
- Be sure to empty and wash the skimmer baskets on a regular basis to keep them clear of leaves
and any other waste. Baskets should be replaced if they are damaged.
- Be sure to empty the basket of the pump pre-fi lter, clearing away leaves and any other waste.
Replace the basket in the event of damage.
- Regulate the suction and return valves by adjusting the valve's pressure switch before setting the
fi lter wash pressure. This operation should be repeated whenever a component is changed or added
to the installation or whenever the regulation setting of the valves is changed.
3.2 SPECIFIC VALVE MAINTENANCE
The internal elements of the valve require regular maintenance in accordance with the following
specifi cations:
- Perform all operations with the pump off and with the input and output valves to the fi lter and
the multiport valve closed.
- Remove the actuator as described in point 6.2 of the manual.
- Remove the remaining 3 screws holding the valve cover in place.
- Remove the cover to allow access to the internal distributor.
- Lift the distributor and clean the area around the distributor seal, clearing away any residue that
may hinder rotation.
- At least once a year, grease the O-rings on the distributor shaft to facilitate the movement of the
distributor. The grease used to lubricate the O-rings should be TURMSILON GL320 NLGI 1-2
(LUBCON). The manufacturer supplies the specifi ed grease together with the valve. The guarantee
will be valid provided that all installation and maintenance operations are carried out correctly.

3.3 GUARANTEES.

The valves leave the factory in a fully tested condition, which enables us to guarantee operation.
The guarantee will be effective provided that the installation and maintenance has been correctly
carried out and this requires that the actual installation operation be performed by a person with
the necessary qualifi cations for this type of work.
Grease
14
