CUTTING BLADE REGULATION (Fig. 8)
n
by using means of screws (1) and their locknut. Every time in order to control the regulation you have first to disassemble the hood then slowly make
the pulley to turn (2) and then verify if the blades are easily moving.
HANDLEBAR SIDE ADJUSTMENT (Fig. 14)
n
starting to work, to regulate the handlebar according to operator needs in order to make the machine easier to handle in every position. The side
handlebar adjustment can be obtained on 3 different positions: please follow the steps: turn the lever anticlockwise (8) to detatch the clamping
EN
regulate the handle in the needed position. Fix the handlebar again turning the lever (8) clockwise and check that teeth/gears should be fully conncted.
n SERVICE AND GARAGING
on safety conditions. Leave the machine to cool before garaging anyhow don't room it if the tank still contains some fuel as the vapours could reach
some blazes or sparks. The fuel tank is to be drained outdoors only. To lower the fire danger , keep the engine , the silencer and the fuel area free
from leaves , grass or greasy substances.
GEARBOX (fig.9) lubricating : use SAE 80 Please verify the oil level before switch the engine on. The oil level can be verified unscrewing the cap
placed on the side of the gearbox. Please change / check the oil level every 60 working hours.
ATTENTION! The used oil must not be drained into the sewer system or waterworks. In order to prevent any pollution to the water-table. Most garages
have used oil deposits, or use the authorized deposits according to your local authority regulations.
TRANSMISSION SCYTHING BAR (Fig. 10) greasing point (1) Important : after every use of the scythe-mower, please clean and grease the scything
bar and all parts mechanisms.
ENGINE SERVICING ( please read the specific part). The motormower is delivered equipped with a 4 stroke engine , NO OIL is included. Please fill
the tank in up to the shown level ( capacity about 0,500 kg.) . Referring to the oil/viscosity type, please follow the engine producer instructions.
SCYTHING BAR SERVICING : the motormower is undoubtly one of the most used agricultural equipment and need a good and frequent servicing.
We recommend you to clean very deeply after every use. If the machine is not used for long periods it is ESSENTIAL to protect the blade and the
bar using some anticorrosive and antioxidant materials. The presence of impurities or foreign bodies on the meadow, damages the teeth sharpening
of the scything bar. It is useful to sharpen the blade and check the teeth integrity every 10 hours use, Only if you keep a good sharpening teeth level
you can obtain the best grass cut. Furthermore it is good to perform a periodical control and a possible setting up of the " clearance" of the blade in
the sliding supports. In case the machine is equipped with pneumatic wheels , You are kindly requested to periodically verify the inflation pressure
level for the tires : the recommended value is 21 PSI ( 1,5 Bar) . However be careful not to exceed the maximum value indicated on the tire itself.
BLADE SHARPENING (Fig. 11)
n
10 hours working. To obtain a perfect sharpening you need to use and electric sharpening machine ( 15.000/20.000 turns/minute) , grinding-headed
with a diameter 25 mm and lenght 35 mm. The blade has to be sharpened from the internal part of the rod to tip.end section using the head grinding.
The blade sections have to be sharpened in a 25° deg. angle.
REPLACEMENT THE SCYTHING BLADE (Fig.12)
n
22
the knife out with a pin push into hole (2). We recommend changing the knife after 2 or 3 sharpenings. The bottom knife should be changed after the
cutting knife should be changed after a couple of changes of the upper one. In the meantime you have to change the plastic knife guides (3).
After the blade substitution or after some working hours the knife-guide should be regulated
The mower handlebar can be both side and height adjusted. It would be better before
Keep attention that all the nuts, screws and bolts are tightened in order to guarantee a good machine working
According to the frequency and the type of use , the cutting sections have to be sharpened about every
To remove the top knife to change and sharpen it, remove screws (1) and pull
