Attachments
Maintenance of attachments
Working with the standard bucket
Inadmissible work procedures
Fig. 170: Working with the swivel force
Fig. 171: Working with the traveling force
OM 803 us – Edition 3.7 * 803b340.fm
Information!
Please refer to the Operator's and maintenance manual of the attachment
manufacturer for using and performing maintenance on attachments such as
hammers, etc.
Information!
Check the auxiliary hydraulics pedal for correct function.
Information!
Correct maintenance and service is absolutely necessary for smooth and con-
tinuous operation, and for an increased service life of the attachments.
Observe the lubrication and maintenance instructions in the Operator's Manu-
als of the attachments.
The following section describes work operations with the machine equipped with the
standard bucket.
The standard bucket is mainly used for earth-moving applications, and for loosening, pick-
ing up, digging and loading loose material (or material to be loosened).
Working with the swivel force
Do not use the swivel force of the upper carriage to compact the ground or tear down
piles or walls.
Do not touch the ground with the bucket as you rotate the upper carriage.
Working this way damages the attachments.
Working with the traveling force
Do not allow the bucket to penetrate into the ground and do not excavate by using the
traveling force of the machine.
Working this way can damage the machine or the attachments.
Operation
3-79
