Lorsque l'emploi des disques pro-
tège-plants n'est pas souhaitable,
il est possible de les maintenir en
position relevée (Fig.4). Le plat
soudé sur la bague (A), solidaire
de l'axe de rotation du bras, vient
en appui sur le buttoir (B).
All manuals and user guides at all-guides.com
When the use of plant-protection
discs is not desired, they can be
maintained in a raised position
(Fig. 4). The flat welded onto ring
(A), integral with the axis of rota-
tion of the arm, presses against
the ridger (B)..
Page 21
When the use of plant-protection
discs is not desired, they can be
maintained in a raised position
(Fig. 4). The flat welded onto ring
(A), integral with the axis of rota-
tion of the arm, presses against
the ridger (B).
