To obtain clear and high quality ECG signal, the lead wire measurement can be used.
Connect the lead wire firmly to the lead wire socket of the device. Place the electrodes
and connect the lead wires as Figure 2.10E to obtain the Lead II ECG signal; if you want
to measure Lead I and Lead III ECG signal, according to the following table to connect
the lead wires to the electrodes (note: lead wire is optional).
Safety Instruction for ECG Measurement
1. Check the device to make sure that there is no visible
damage that may affect user's safety and measurement
performance. Stop using the unit, when there is obvious
damage.
2. Do NOT make diagnosis oneself by the measurement
and measurement results, always consult the doctor
if abnormal information is presented frequently.
3. Do NOT use the device in the bathroom or moist circumstance.
ENGLISH
Lead wire measurement
Figure 2.10E
