2
Install the filters
1
Place the True HEPA Filter
within the Filter Frame.
Please make sure that the True HEPA
Filter is placed in proper orientation.
Do not install the filter backwards or the
unit will not operate properly.
Place the Active Carbon Filter on top
of the True HEPA Filter with the
bands (2 places) facing up.
2 Place the Pre-filter through the
bands (2 places) located in the
corners of the Active Carbon
Filter.
Insert the tabs of the pre-filter into the as-
sociated holes of the Filter Frame.
3 Mount the Filter Frame to
the main unit.
4
Replace the Front Panel back
onto the main unit.
5 Fill in the usage start date on the
Date Label.
Use the date as a guide for the Filter Re-
placement schedule.
Filter Frame
Filter Frame
Front Panel
E-9
Band
Holes
Main unit
Active Carbon
Filter
True
HEPA
Filter
Tabs (4 places)
Side View
Date Label
