1 0 (eject) /
(angle) button
• Open/close the control panel (and eject
the disc, if any, when opened).
• Adjust the control panel angle if held
then pressed.
2 Remote sensor
DO NOT expose the remote sensor on
the control panel to strong light (direct
sunlight or artificial lighting).
3 PICT button
Used to download/delete the animations
and still image for the graphic display.
4 SOURCE button
Select the source.
5 4/¢ (
/ ) buttons
• Searches for stations (Auto Search) if
pressed, or
Skips frequencies after pressed and held
(Manual Search).
• Change the tracks on the disc.
• On the control panel only: while
operating the Menus, it works to select
the Menu items/values.
6 Color display window
7 Reset button
Reset the built-in microcomputer.
8 Volume (VOL) +/– button(s)
Adjust the volume level.
9
(Standby/On/Attenuator)
button
Turns on and off the power, and also
attenuates the sounds.
p DISP (BACK) button
• Change the information shown on the
display.
• When operating the Menus, it works as
the BACK button (to go back to the
previous step).
q BAND (OK) button
• Select the FM/AM band (FM1, FM2,
FM3, and AM).
• When operating the Menus, it works as
the OK button (to confirm your
selection).
w MENU button
Show the Main Menu (or erase it).
e 5/∞ buttons
• Change the preset stations.
• Change the folder on the MP3/WMA
discs.
• On the control panel only: while
operating the Menus, it works to select
the Menu items/values.
r
(control panel release) button
Detach the control panel.
t Number buttons
• Select the preset station if pressed, or
Store a station if pressed and held.
• Select the tracks while playing CDs.
• Select the folders while playing MP3/
WMA discs.
• Select the discs while operating the CD
changer.
y ANGLE button
Adjust the control panel angle.
u BAND button
Select the FM/AM band (FM1, FM2,
FM3, and AM).
