buttons, a characteristic click will inform you
that the connectors are properly fastened and
the indicators (O) will change to green (Fig. 6).
Push the child car seat firmly against the back-
rest of the car (Fig. 7).
WARNING! Pull the child car seat towards you
to make sure that the child car seat has been
installed correctly on both sides. Also check
that the child car seat is resting perfectly
against the backrest of the car.
The installation of the car seat can ONLY be
considered complete after the installation of
the support leg (Q).
Position the support leg (Q) and use the ad-
justment button (T) to make the final adjust-
ments (Fig. 8). When the support leg is prop-
erly installed the indicator (U) will turn green
(Fig. 9).
WARNING! Be sure that the support leg is
in contact with the floor of the vehicle at all
times.
WARNING! The only allowed positions when
the vehicle is travelling are forward facing or
rear facing (Fig. 10).
WARNING! The child car seat must be in-
stalled in the rear facing position until the
child is older than 15 months.
Press the car seat rotation button (K) while
simultaneously turning the seat toward you
(Fig. 11); the only purpose of this position is
to simplify the task of positioning the child in
the car seat.
Before seating your child in the child car seat,
press the harness adjustment button (E) while
holding the two car seat harnesses under
the shoulder straps and pulling them toward
yourself to slacken them (Fig. 12).
Release the car seat safety harness buckle (D)
by pressing on the red button (Fig. 13) and po-
sition the child in the car seat.
WARNING! Always ensure that the child is sit-
ting with their body flat against the backrest
of the child car seat and that the crotch strap
(I) is positioned correctly.
Take the belts and join the two tabs of the
buckle (Fig. 14). Push the two tabs firmly inside
the buckle until you hear a "click" (Fig. 15). To
ensure safety, the two tabs of the buckle were
designed so that they cannot be fastened one
at a time or alone.
To tension the car seat safety harnesses, pull the
harness adjustment strap (F), until the harness-
es adhere to the child's body correctly (Fig. 16).
WARNING! Do not over-tighten the harnesses
around the child: if you can insert one finger
between the harness and your child's shoul-
ders, it means that they are tightened correctly.
WARNING! Check that the harness is not
twisted.
Use the rotation button (K) to turn the car seat
until it is in the rear facing position (Fig.17).
WARNING! The REDUCER CUSHION is to be
used from birth to 75 cm. Refer to paragraph
8. REDUCER CUSHION.
WARNING! In this configuration the seat can
recline in two positions. Refer to paragraph 10.
ADJUSTING THE INCLINATION OF THE CHILD
CAR SEAT.
5. INSTALLING THE CAR SEAT AND SEAT-
ING THE CHILD (76-105 cm) (≤ 18 kg)
WARNING! Forward facing installation is only
allowed if the child is older than 15 months.
See the previous paragraph, 4, for car seat
installation. INSTALLING THE CAR SEAT AND
SEATING THE CHILD (40-105 cm) (≤ 18 kg).
Follow the instructions provided below when
seating the child.
To adjust the height of the car seat safety
harnesses and headrest refer to paragraph 9.
ADJUSTING THE HEADREST AND HARNESSES.
Press the car seat rotation button (K) while
simultaneously turning the seat toward you
(Fig. 18); the only purpose of this position is
to simplify the task of positioning the child in
the car seat.
Before seating your child in the child car seat,
press the harness adjustment button (E) while
holding the two car seat harnesses under
the shoulder straps and pulling them toward
yourself to slacken them (Fig. 19).
Release the car seat safety harness buckle (D)
by pressing on the red button (Fig. 20) and po-
sition the child in the car seat.
WARNING! Always ensure that the child is sit-
