Logic
Definition
Block pulses
IBL OPEN
during opening
Ice feature
ice
OPEN IN OTHER
Open in other
direction
DIRECT.
Configuration
of safety input
SAFE 1
SAFE 1.
72
Configuration
of safety input
SAFE 2
SAFE 2.
73
Configuration of
command input
IC 1
IC 1.
61
Configuration of
command input
IC 2
IC 2.
62
Configuration
of the 1st radio
1ch
channel com-
mand
Configuration
of the 2nd
2ch
radio channel
command
Configuration
of the 3rd radio
3 ch
channel com-
mand
Configuration
of the 4th radio
4 ch
channel com-
mand
Configuration of
AUX 3 output.
AUX 3
26-37
ENGLISH
Cross
out
Default
setting
used
0
Pulse from inputs configured as Start E, Start I, Ped has effect during opening.
0
1
Pulse from inputs configured as Start E, Start I, Ped has no effect during opening.
0
The Amperostop safety trip threshold stays at the same set value.
The controller automatically adjusts the obstacle alarm trip threshold at each start up.
Check that the force of impact measured at the points provided for by standard EN 12445 is lower than the value
1
1
laid down by standard EN 12453. If in doubt, use auxiliary safety devices.
This feature is useful when dealing with installations running at low temperatures.
WARNING: once this feature has been activated, you will need to perform an autoset opening and closing cycle.
0
Standard operating mode
1
Opens in other direction to standard operating mode
0
Input configured as Phot (photocell).
1
Input configured as Phot test (tested photocell).
6
2
Input configured as Phot op (photocell active during opening only).
3
Input configured as Phot op test (tested photocell active during opening only).
4
Input configured as Phot cl (photocell active during closing only).
5
Input configured as Phot cl test (tested photocell active during closing only).
6
Input configured as Bar, safety edge.
7
Input configured as Bar, tested safety edge.
8
Input configured as Bar 8k2. (Inactive on SAFE 2).
9
Input configured as Bar OP, safety edge with inversion active only while opening. If while closing, the movement stops.
Input configured as Bar OP TEST, safety edge tested with inversion active only while opening. If while closing, the
10
movement stops.
4
Input configured as Bar OP 8k2, safety edge with inversion active only while opening. If while closing, the movement
11
stops. (Inactive on SAFE 2).
12
Input configured as Bar CL, safety edge with inversion active only while closing. If while opening, the movement stops.
Input configured as Bar CL TEST, safety edge tested with inversion active only while closing. If while opening, the
13
movement stops.
Input configured as Bar CL 8k2, safety edge with inversion active only while closing. If while opening, the movement
14
stops. (Inactive on SAFE 2).
15
Not used
16
Input configured as STAR 8k2. (Inactive on SAFE 2).
0
Input configured as Start E.
1
Input configured as Start I.
0
2
Input configured as Open.
3
Input configured as Close.
4
Input configured as Ped.
4
5
Input configured as Timer.
6
Input configured as Timer Pedestrian.
0
Radio control configured as START E.
1
Radio control configured as Start I.
0
2
Radio control configured as Open.
3
Radio control configured as Close
4
4
Radio control configured as Ped
5
Radio control configured as STOP
6
Not used
9
7
Not used
8
Not used
9
Radio control configured as AUX3 **
10
Radio control configured as EXPO1 **
5
11
Radio control configured as EXPO2 **
12
Not used
0
Output configured as monostable Radio Channel.
1
Output configured as SCA (gate open light).
2
Not used
3
Output configured as ZONE LIGHT
4
Output configured as STAIR LIGHT
5
Not used
6
Output configured as FLASHING LIGHT
7
Not used
0
8
Not used
9
Output configured as Maintenance
10
Output configured as FLASHING LIGHT AND MAINTENANCE
11
Not used
12
Not used
13
Output configured as closed Gate Status
14
Output configured as Bistable Radio Channel
15
Output configured as timed Radio Channel
16
Output configured as open Gate Status
Optional extras
(See
Fig.M).
(See Fig.
M)
HIDE SL SMART BT A150-A300
37
-
