Charging
> Please follow the separate operating instructions of the battery charger used (not included in delivery) and the specifica-
tions of the battery manufacturer.
Only charge rechargeable batteries which are intended for this purpose, conventional batteries must not be recharged.
>
There is a danger of explosion!
> Charge only batteries of the same type and capacity. Observe correct polarity in all electrical connections and when connec-
ting the rechargeable batteries to a charger.
Recharge the batteries only under supervision, on a flame-resistant surface and keep adequate distance from combustible
>
surfaces or objects.
> Check the temperature of the battery occasionally during charging.
NiMH and NiCd batteries can heat up considerably especially at high charge currents (> 1C). The battery may be damaged
on excessive heating (>50°C). In such a case, reduce the charge current.
> Already charged or fully discharged batteries should not be connected and charged.
> Never charge/discharge damaged, expired or deformed rechargeable batteries. There is a danger of fire and explosion!
Battery charger
> Repair and maintenance work may only be carried out by specialists/specialist workshops.
> Do not place operate the device unattended.
> Make sure there is sufficient space between the components to prevent them heating up one another.
Never cover the charging device and rechargeable battery to prevent heat from building up as a result of insufficient air
>
circulation.
3. P
roduct descrIPtIoN
This product is a mounted RC car chassis ready-to-run with four-wheel drive, which is driven by a brushless motor and control-
led by radio using a 2.4 GHz remote control unit that comes with it.
The RC Monster Truck is pre-assembled ready-to-run and comes with built-in remote-control and drive components.
This model is intended both for operation on indoor tracks as well as operation outdoors.
The bodywork, which is ready-printed and cut out as well as the rear spoiler with a carbon look makes for a classy visual
impression, and the decals included can be used to customise your model.
The plastic channel chassis is light, rigid and provides the components protection against splashed water and pebbles thrown
up. The chassis obtains additional sturdiness from a top deck made of chassis aluminium.
A low-maintenance brushless motor provides satisfaction with higher power, greater torque and a higher efficiency factor
than conventional brushed motors. A heat sink ensures heat dissipation even under the most severe conditions.
The drive is carried out directly via the motor pinion onto the main gear wheel. From there one drive shaft each made of metal
meshes in the encapsulated differentials of the front and rear axles, thus bringing about four-wheel drive. The differentials
in the front and rear axles provide for speed compensation between the wheel on the inside and the wheel on the outside of
curves and has metal gears. The model is entyrely ball-bearing-mounted.
A programmable electronic speed controller with a fan attached is geared in optimum fashion to the brushless motor and
provides satisfaction through excellent starting behaviour, acceleration and excellent synchronisation.
The high-performance RS 90MGBB steering servo with metal gearbox and two ball bearings has high controlling torque
amounting to 88.3 Ncm and high control speed with maximum stability. A servo saver also provides protection for the servo
against sharp impacts against the wheels.
In this 2.4 GHz remote control set with 2 channels, you have a radio control system that is ideally suited for primarily model
cars and model ships. Its proportional control channels allow 2 control functions to be remotely controlled independent of
one another.
The 2.4 GHz transmitter and the receiver tuned to it do not work on a frequency predetermined by the sender and receiver
crystal. Each time they are switched on, the transmitter and receiver scan the frequency band for an available, open frequency
on which the radio link is then established.

.1 Intended use

This product has been designed solely for private use in the field of modelling and has operating times appropriate to this use.
This product is not approved either for commercial or industrial nor for continuous operation.
Any improper use can result in endangerment to people as well as damage to the product and dangers involved in such, like
the loss of control over the model, short-circuits, fires, electric shock, etc.
Comply with the safety instructions in these Operating Instructions. They contain important information on how to handle
this product.
The product is suitable for children under 14 years only under adult supervision.
- 1 -
