Philips RESPIRONICS SimplyGo Mini Mode D'emploi page 57

SimplyGo Mini User Manual
Sound Level
Audio Alarm
Maximum Outlet
Pressure
SimplyGo Mini Battery
Chemistry
Battery Options
Dimensions
Weight
Watt-hour Rating Per
Standard Battery
Battery Duration
* Battery Duration times are based on new, fully charged batteries used
with a new SimplyGo Mini system� Battery duration times will degrade
with battery age, environmental operating conditions, use over time, and
operational condition of the concentrator�
Charge Time
54
42 dBA typical at setting 2 and 20 BPM
48 dBA typical at setting 5 and 20 BPM
(when measured at 1 m from front of device)
Maximum Sound Power of 63 dBA and Maximum
Sound Pressure level of 55 dBA per ISO 80601-2-69
45 dBA or greater
20 psig
Lithium Ion 14�4 VDC (nominal)
Standard Battery
Extended Battery (equals 2 standard batteries)
7�9 in x 3�6 in x 1�0 in (standard battery)
(20�1 cm x 9�1 cm x 2�5 cm)
7�9 in x 3�6 in x 1�9 in (extended battery)
(20�1 cm x 9�1 cm x 4�8 cm)
1�1 lbs (0�50 kg) (standard battery)
2�1 lbs (0�95 kg) (extended battery)
3�4 Ah x 3�6 V x 8 cells = 97�9 Wh
Up to 4�5 hours (Pulse setting of 2 at 20 BPM with
Standard battery)
Up to 9 hours (Pulse setting of 2 at 20 BPM with
Extended battery)
Maximum recharge time is 4 hours for the standard
battery and 8 hours for the extended battery from
fully discharged to fully charged, depending on the
power source and usage�
