14. Ignition switch
15. Choke lever
16. Fuel cap
17. Flats on drive links
18. Brake position
19. Run position
20. Silencer
21. Start position
22. Run position
23. Kickback danger zone
24. Clean the chain brake
25. Idle speed screw "T"
26. Pull
27. Push
28. Rotational kickback
29. Proper hand grip position
30. Improper grip
31. Proper grip
32. Chain line
33. Thumbs on underside of handle bar
34. Straight arm
35. Planned line of fall
36. 135 degree from planned line of fall
37. Path of safe retreat
38. Hinge – 5 cm or 1/10 diameter
39. Back cut
40. Notch approx. 1/3 diameter of the trunk
41. Hinge
42. Wedge
43. Vertical cut
44. Lodge section
45. Horizontal cut
46. Kickback
47. Log supported at one end
48. Finishing cut
49. Load
50. 1st cut 1/3 diameter
51. Log supported at both ends
52. Overbucking
53. Underbucking
54. Second cut
55. Cut limbs one at a time and leave support limbs under
tree until log is cut
56. Springpole
57. Chain drive links
58. Cutters
59. Chain rotation
60. Bar groove
61. Adjusting pin
62. Chain tensioning pin hole
63. Sprocket
64. Rotate clutch cover knob clockwise to secure
65. Loosen chain
66. Tighten chain
English (Original instructions)
67. Raker (depth gauge) clearance
68. Inspect drive sprocket
69. Gullet
70. Heel
71. Rivet hole
72. Top plate
73. Cutting corner
74. Side plate
75. depth gauge
76. Toe
77. Left hand cutters
78. Right hand cutters
79. Top plate filing angle
80. Correct
81. Less than 30 degree
82. More than 30 degree
83. Incorrect
84. Side plate filing angle
85. Hook
86. Backward slope
87. Depth gauge jointer
88. Flat file
89. Restore original shape by rounding the front
90. Lubricating hole
91. Air filter
92. Chain brake
93. Post
94. Starter cover
95. Clean Engine fins
96. Clean flywheel fins
97. Fuel filter
98. Deflector
99. Deflector retaining nut
100. Spark arrestor
101. Bumper spike bar
102. Bolt & nut
103. Gasket
104. T25 Torx Screwdriver
KNOW YOUR TOOL.
See figure 1. 1a - 1b.
The safe use of the product requires an understanding of
the information on the tool and in this operator's manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
Choke lever
The choke lever opens and closes the choke valve in the
carburettor.
Front hand guard/chain brake
The chain brake is designed to quickly stop the chain from
rotating. When the front hand guard/chain brake is pushed
