Power Supply
The mains connection is on the rear of the unit.
The power supply voltage is set by the factory for100-115V(nom. 110V) or 220-240V (nom. 230V) working.
The setting is indicated by the indented metal strip on the fuse panel. Contact your dealer if the voltage
needs to be changed.
The mains indicator lamp on the keyboard is always lit when the unit is connected to the mains supply. The unit
can either be operated from the mains supply or from the built-in rechargeable battery.
Changing a Mains Fuse
If it is necessary to change a fuse, always replace with the correct rating i.e 2x200mAT for 230V, or
2x315mAT for 110V .
To change a fuse press the two retaining lugs on side of the fuse panel (situated below the mains connector on the
back panel. Remove the fuse panel and replace the fuse(s). Click back the fuse panel.

Intended Use

The CARDIOVIT AT-2 is a 6-channel ECG recorder with all (12) ECG signals simultaneously processed to provide
instant ECG recordings. Two automatic recording modes can be individually preset to enable one button ECG
recording of preferred print formats.
