Preface

This manual provides product safety and compliance, how to connect and power on the instrument, and an introduction to the
instrument features, controls and basic operations. See the product Help file for more detailed information.

Key features

Welcome to the 6 Series Low Profile Digitizer LPD64.
Low profile instrument with no display, comes ready to install in a 2U rack mount space
■
4 channels with 50 Ω SMA inputs
■
1, 2.5, 4, 6, and 8 GHz bandwidths on all channels
■
Maximum 25 GS/s sample rate on all channels
■
125 M points record length on all channels (optional 250 M points available)
■
12 bits A/D resolution
■
Lowest-in-class noise
■
Highest-in-class ENOB (8.2 bits at 1 GHz)
■
500,000 waveforms/second maximum waveform capture rate
■
No set limit on the number of math, reference, and bus waveforms you can create (the number of waveforms depends on
■
available system memory)
Spectrum View enables simple, intuitive frequency domain analysis, independent of time domain controls, to show a
■
spectral trace for each channel
Real-Time 2 GHz DDC for RF bandwidth
■
™
FastFrame segmented memory acquisition uses multiple trigger events to capture widely spaced events of interest at high
■
sample rates while conserving acquisition memory
Integrated options include a 50 MHz arbitrary/function generator (AFG), and a Digital Voltmeter (DVM) and trigger frequency
■
counter
Advanced serial bus triggering and analysis options let you decode and trigger on industry standard buses. See the Serial
■
bus and trigger options Help topic
Power, DPM, and Jitter options provide additional measurement and analysis functions. See the Advanced Power Analysis,
■
DPM Analysis, and Advanced Jitter Analysis Help topics
LPD64 Installation and Safety Manual vii
