Adventurer Pro

3.4.2 Navigation

The Adventurer Pro menu structure consists of three levels. The top level is the main menu which
consists of a number of sub-menus.
Enter
CALIBRATION SETUP
END LOCKOUT
SECOND LEVEL
The second level of the menu structure is the
sub-menu level. Each sub-menu is a loop
that consists of a number of menu items.
BOTTOM LEVEL
The bottom level of the menu structure is the
menu item level. Each menu item level consists
of two or more settings

3.4.3 Changing Settings

To change a menu setting, perform the following steps:
ENTER THE MENU
Press and hold the Menu button until MENU appears on the primary display. Release the button
and the first sub-menu appears on the secondary display (blinking). Note: A blinking display in
the menu indicates a choice must be made using the Yes, No or Back buttons.
SELECT THE SUB-MENU
Press the No button to select the next sub-menu or the Back button to select the previous sub-
menu in the loop. Press the Yes button to select the sub-menu that appears on the secondary
display (blinking). The sub-menu name now appears on the primary display and the first menu
item in the sub-menu now appears on the secondary display (blinking).
SELECT THE MENU ITEM
Press the No button to select the next setting or the Back button to select the previous setting in
the loop. Press the Yes button to select and save the setting on the secondary display (blinking)
as the new menu item setting.
EXITING THE MENU
Press the Exit button at any time to quickly exit the menu or select END sub-menu and press the
Yes button.
TOP LEVEL
READOUT MODE
RESET GLP PRINT GLP DATA
Typical Sub-menu
Typical Menu Item
Typical Setting
UNIT PRINT-1 PRINT-2
RS232-2 RS232-1
POWER
END RS232
BAUD
HANDSHAKE
PARITY
7 EVEN
8 NOP
7 ODD
7 NOP
EN-11
