Transporting Machine; Storing Machine; Recommended Stock Items - Nobles SPEED SCRUB 1701 PLUS Manuel Opérateur

OPERATION
c. Use wire brush to clean terminal post and
cable connections.
d. After cleaning, apply a coating of clear battery
post protectant to terminals and cable
connections.
5. Check for loose or worn cables. Replace if worn.

TRANSPORTING MACHINE

When transporting machine by use of trailer or truck,
be certain to follow tie--down procedures below:
FOR SAFETY: When using machine, go slow on
inclines and slippery surfaces.
1. Remove squeegee from machine and raise scrub
head. Leave pad or brush installed.
2. Load machine using a recommended loading
ramp.
3. Position front of machine up against front of trailer
or truck. Once machine is positioned, lower brush
head.
4. Place a block behind the wheels.
5. Place tie--down straps over top of machine and
secure straps to floor. It may be necessary to
install tie--down brackets to the floor of your trailer
or truck.
FOR SAFETY: When transporting machine, use a
recommended ramp when loading/unloading
into/off truck or trailer, use tie- -down straps to
secure machine to truck or trailer.
18
Home Find... Go To..

STORING MACHINE

1. Before storing machine, be certain to rinse tanks
and drain machine of all water.
2. Store machine in a dry area with squeegee
removed and scrub head in the raised position.
3. Remove recovery tank lid to promote air
circulation.
ATTENTION: If storing machine in freezing
temperatures, be certain to drain machine of all
water. Damage due to freezing temperatures is not
covered by warranty.
WARNING: Do Not Use Outdoors. Do Not
Expose To Rain. Store Indoors.

RECOMMENDED STOCK ITEMS

Refer to Standard Parts section for recommended
stock items. Stock Items are clearly identified with a
bullet preceding the parts description. See example
below:
Speed Scrub 1701 Plus (02- -04)
