Installation

1. Required tools

Have the following tools for installing this product:
adjustable end wrench, Phillips head screwdriver,
flat-blade screwdriver.
2. Install the junction fitting
1) Close the water shutoff valve fully.
2) Flush the toilet and empty all the water from the
tank.
3) Place a wash bowl or other container
underneath the tank water supply hose. Then
loosen the box nut on the tank inlet side and
remove it.
CAUTION
• Be careful not to damage the water supply hose.
4) Place the packing in the junction fitting box nut
and connect the tank inlet to the junction fitting.
CAUTION
• Do not overtighten the nut.
5) Insert the packing in the tank water supply hose
box nut and connect the tank water supply hose
to the junction fitting.
CAUTION
• Do not overtighten the nut.
Tank Water
Supply Hose
Installation
Figure
Packing
Tank Water
Supply Hose
Water Shutoff
11 - EN -
Bowl Cock Side
Box Nut
Water Shutoff Valve
Close
Tank Inlet
Junction
Fitting
Packing
Valve
Box Nut
