Maintaining This Product

Cleaning the Seat Unit

Periodically, wipe off the seat unit with
a soft cloth dampened with water.
Changing Nozzle Tips
a) Ensure SpaLet ® seat is powered ON.
b) Raise the toilet lid and toilet seat.
c) Under non-seated situation to clean nozzles manually,
press "Nozzle Cleaning" button for over 2 seconds.
* After water fl ows out from the nozzle area for approximately
10 seconds, the back cleansing nozzle extends, but the
nozzle does not discharge any water.
d) Turn the nozzle tip counterclockwise and align the
Detach mark on the right side of the nozzle tip with the
Center mark on the nozzle unit, and then pull out the
nozzle tip.
* Pull the nozzle slightly, hold the nozzle at its base with your
hand, and then remove the nozzle tip.
e) Align the Detach mark on the right side of the nozzle tip
with the Center mark on the nozzle unit, and then in-
sert the new nozzle tip fully and turn it clockwise until it
can no longer be turned.
* Hold the nozzle at its base with your hand when installing
the nozzle tip.

Cleaning the Nozzles

a) SpaLet ® seat must be powered ON to clean
nozzle tip.
b) Raise the toilet lid and toilet seat
c) Under non-seated situation to clean nozzles
manually, press "Nozzle Cleaning" button for
over 2 seconds.
After water fl ows out from the nozzle area for
approximately 10 seconds, the back cleansing
nozzle extends, but the nozzle does not discharge
any water.
d) Use a soft sponge to clean any accumulated
debris.
e) Press "Cleansing" button again.
The front washing nozzle extends.
f) Use a soft sponge to clean any accumulated
debris.
Turn
counterclockwise
28 - EN -
O-ring
Center mark
①
O-ring
② Pull
Detach mark
Center mark
