Machine Components - Nobles SPEED SCRUB 2001 Manuel Opérateur

OPERATION

MACHINE COMPONENTS

3
6
24
10
13
11
25
1. Control Grips
2. Vacuum ON/OFF Switch
3. Brush ON/OFF Switch
4. Battery Meter
5. Brush Motor Circuit Breaker
6. Squeegee Lift Lever
7. Solution Flow Lever
8. Solution Flow Adjustment Knob
9. Adjustable Control Console Levers
10. Brush Lift Lever
11. Brush Lift Foot Lever
12. Recovery Tank Drain Hose
13. Solution Tank Drain Hose
6
4
2
7
1
5
12
9
23
8
14
Home Find... Go To..
16
18
19
23
21
14. Squeegee Assembly
15. Control Console
16. Recovery Tank
17. Recovery Tank Lid
18. Solution Tank Fill Door
19. Safety Lights
20. Main Wheels
21. Scrub Head
22. Scrub Head Skirt
23. Wall Rollers
24. Rear Fill Port
25. Vacuum Hose
26. Battery Compartment
17
26
20
22
Speed Scrub 2001 Battery (04- -04)
15
