7. Attach brush/pad driver to motor hub. Align 3
mounting studs with slots in motor hub and give
the driver a quick turn toward the spring clip on the
motor hub to attach brush/pad driver. Be certain
that spring clip locks into one of the studs on the
driver before operating machine (Figure 6).
FIG. 6
8. Raise brush head. To raise brush head, step down
firmly on the bottom brush lift foot pedal until brush
locks into the raised position (Figure 7).
FIG. 7

FILLING SOLUTION TANK

1. Push machine to the fill station. Raise squeegee
and brush head when transporting.
2. Pull solution flow lever completely back to shut off
solution flow (Figure 8).
FIG. 8
Speed Scrub 2001 Battery (04- -04)
Home Find... Go To..
3. Open solution fill door at front of machine and fill
solution tank with 38L (10 gal) of clean water,
60°C (140°F) maximum temperature. Or use the
rear fill port to fill solution tank. The clear tube
below the fill port has 19L (5 gal) increment
markers to indicate amount of water in tank
(Figure 9).
NOTE: The water must NOT be hotter than 60
(140 F) or tank damage may occur.
°
FIG. 9
NOTE: If filling with a bucket be certain that bucket is
clean. This will prevent possible solution line clogs.
4. Add cleaning detergent according to mixing
instructions on bottle.
FOR SAFETY: When using machine, follow mixing
and handling instructions on chemical containers.
ATTENTION: Use only recommended detergents.
Machine damage due to improper detergent usage
will void the manufacturer's warranty. Contact
your Tennant Sales Representative for detergent
recommendations.
WARNING: Do Not Use Flammable Liquids Or
Operate Machine In Or Near Flammable Liquids,
Vapors Or Combustible Dusts.
OPERATION
