Prevailing Torque Phase - Georges Renault DEVICE NET Manuel Opérateur

6.2.2.1 Search sequence phase
6.2.2.1.1 Description of a search sequence phase
Instructions
Rotation type
Rotation value (angle or time)
Stop time
Number of rotations
Direction of rotation
Rotation speed
Power
6.2.2.1.2 Coding a search sequence phase "S1"
@ Byte @ word
0X600 0X300 Header (station, cycle, phase, etc)
Rotation type ("A" or "T")
Rotation value
Number of rotations
Stop time
Direction of rotation ("++" / "--" / "+- ")
Rotation speed
Power
6.2.2.2 Run Down speed phase
6.2.2.2.1 Description of a run down speed phase
Instructions
Target torque
Angle threshold
Direction of rotation
Rotation speed
Power
6.2.2.2.2 Coding a run down speed phase "D1"
@ Byte @ word
0X600 0X300 Header (station, cycle, phase, etc)
Target torque
Angle threshold
Direction of rotation ("++" / "--")
Rotation speed
Power
Operator's Manual
DEVICE NET
Format
Integer
Floating
Floating
Integer
Integer
Integer
Integer
Description
Format
Floating
Floating
Integer
Integer
Integer
Description
Search
sequence
●
●
●
●
●
●
●
Access Size
W/R 12
W/R 2 "XX"
W/R 6 "XXXXXX"
W/R 2 "XX"
W/R 4 "XXXX"
W/R 2 "XX"
W/R 4 "XXXX"
W/R 4 "XXXX"
36
Prevailing
torque
●
●
●
●
●
Acces Size
s
W/R 12
W/R 6 "XXXXXX"
W/R 6 "XXXXXX"
W/R 2 "XX"
W/R 4 "XXXX"
W/R 4 "XXXX"
34
6159932680-01
English
15/28
Value
Value
