6159932680-01
English
12/28
Note: these options can be accessed only through a specific configuration routine.
5.3.2 -

"Result per Spindle" Reading Area

(Table A3)
5.3.3 -

Size of a Result per Spindle

According to the 3 options programmed in the tightening controller, the size of a spindle result takes the following values:
Mask of values
Torque
(word no. 10 = 0x0001)
Torque, Angle
(word no. 10 = 0x0003)
Torque + Angle + Torque rate
(word no. 10 = 0x0007)
5.3.4 -

Example of Addresses of Results per Spindle

Typical example: final value + tolerance of an ASCII coded torque + angle + torque rate result
Acyclic request
Mapping
Class 100
Address
Instance
0x3000
0x50
0x3002
0x51
.....
0x5000
0x60
0x5002
0x61
.....

5.4 - ISaGRAF specific area

This area allows you to meet specific applications: it can be used only with an IsaGRAF application. This memory area can be
accessed both through the PLC and the ISaGRAF application of the tightening controller. It is not associated to a station, but to
a controller. If you want to use two different storage areas for each station, you must define your own memory mapping and
divide it into 2 parts.
This storage area is not re-initialized when switching on the station. The data saved in this memory are therefore stored, and do
not require to be downloaded by the PLC when switching on the station.
(Size used depends on type of application).
Acyclic request
Mapping
Class 100
Address
Instance
0x7000
0x38
..
..
0xEFFF
0x77

5.5 - Option Area

This storage area is in read-only mode. It allows you to display the 3 options used to code the result per spindle area, as well as
the size for the specific area.
Format 0 (full)
Tolerance, final, trend
ASCII
Natural
20
14
(6x3 + 2)
(4x3 + 2)
40
28
((6x3 + 2)x2)
(4x3 + 2)x2
60
42
((6x3 + 2)x3)
(4x3 + 2)x3
Attribute
0
Station 1 global report
Spindle no.
Station 1 result per spindle
[1,32]
0
Station 2 global report
Spindle no.
Station 2 result per spindle
[1,32]
Attribute
0x00-0xFF
..
Memory to be accessed via ISaGRAF
0x00-0xFF
Operator's Manual
DEVICE NET
Format 1 (partial)
Final , trend
ASCII
Natural
8
(6 + 2)
(4 + 2)
16
((6 + 2)x2)
(4 + 2)x2
24
((6 + 2)x3)
(4 + 2)x3
Station 1
Description
Description
Format 2 (reduced)
Trend
ASCII
Natural
6
2
12
4
(2x2)
18
6
(2x3)
Access
Size (bytes)
R
2
R
60
R
2
R
60
Access
Size (bytes)
W/R
240
2
4
(2x2)
6
(2x3)
Value
Note 1
Note 2
Note 1
Value
